* 3.5-9X21 Infrared Hunting Camera: Digital monocular with CMOS sensor achieves clear view up to 9X optical magnification and 8X digital zoom magnification with 21mm objective lens. Built-in infrared Illuminator enable observe target in totally dark condition and the range up to 656 feet. CCD auxiliary lighting keep the image clear and bright. During the day or low light, observation distance is infinite. Eyepiece adjustable diopter and eye cup can be folded down for wearing eyeglasses observation.
* High definition: Digital night vision has photo shooting and video recording with sound, and playback functions on 0.25 inch TFT LCD. Resolution of image is 320x240. It also can connect computer with USB cable and connect TV with TV cable, USB and AV OUT sockets are equipped that allow you can share your images and videos to your family and social media. 8G TF card included can enlarge the storage. You can rotate the focusing handwheel and it's easy to adjust it until you get a clear image.
* Can be connected with tripod: The monocular features a threaded tripod mount and weaver rail for securing to a tripod or connecting an additional IR illuminator. It recharges the battery using the DC IN socket by a power adapter. It is suitable for hunting and scouting game; security and surveillance; camping fun; exploring caves; nighttime navigation; night fishing and boating; wildlife observation; search and rescue; nighttime show; bird watching; scenery.
* Solid framework: Rubber armor with stripes makes it comfortable for use and keeps it from slipping out from your hand. Tight fitting protection makes it usable to withstand the toughest weather conditions.
* Great Hunting Infrared Camera: With various accessories for equipment and easy storage and carrying. Package List: 1x AV Video Cable, 1x USB Cable, 1X8 GB TF card, 1x Power Adapter, 1x Pouch, 1x Accessory Bag, 1x Operating Instructions, 1x Hand Grip Strap, 1x Cleaning Cloths.
Item No. | LR-NV150 | System | 4 modes: capture / video / playback / menu | ||
Imager | Sensor | wide dynamic range high-sensitivity CMOS sensor | single frame image capture | ||
Size | 1/4" | video image record | |||
Resolution | 640x480 | playback image | |||
Video | TFT LCD Resolution | 320x240 | delete image | ||
CVBS Output | CVBS always output with VGA resolution | 5 levels IR switch for USB power, 3 levels IR switch for battery. | |||
USB Output | USB UVC output | 4 levels LCD brightness | |||
Menu Display | OSD menu display | system rest | |||
IR LED | Lighting Device | 3W infared LED with 850nm | auto power save: ON / OFF / 1min / 3min / 5min | ||
Lighting Working | adjustable high-middle-low-off | TV output format: PAL / NTSC | |||
USB Output | UVC Class | yes | flicker: 50 / 60HZ | ||
MSC Class | yes | SD card format | |||
AV Output | yes | date input | |||
Micro SD Card Output | support SDHC 4GB~32GB SD card | language: English / Trad.Chinese / Simp.Chinese / Japanese / French / Deutsch / Korean / Italian / Portuguese / Russian / Spanish / Arabic | |||
Wireless LAN | N/A | version | |||
N/A | Application Mode | Day | yes | ||
N/A | Night | yes | |||
N/A | Dark | yes (with IR ON) | |||
Hardware Buttons | power ON / OFF | Power | DC | SV / 1A | |
mode selection | AA Battery | 4pcs | |||
zoom | Battery Life with IR OFF | 6h | |||
shutter / snap | Low Battery Warning | yes | |||
IR switch | |||||
Operation | preview | ||||
capture JPEG file in SD storage | |||||
record AVI file in SD storage | |||||
playback media file from SD storage |
Item No. | LR-NV150 | Field of Angel | 10° |
Model | Field of View | 175m/1000m | |
Magnification | 3.5~9X | Eye Relief | 18mm |
Clear Aperture | 21mm | Diopter Adjustment | +100°~-400° |
Digital Zoom Magnification | max 2.6X | Near Focus | 3m |
Focus Adjustment | Manual | View Distance at Night | up to 200m |
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
Eyepiece | Focus Ring | IR Illuminator | IR-Cut | USB Port | AV Output | TR-Card Slot | Strap Hole |
9 | 10 | 11 | 12 | 13 | 14 | 15 | |
Battery House | Tripod Hole | Power | Mode Button | Zoom Button | IR Button | Snap Button |
LR-NV150 | ||
Product | Dimension (WxHxD) | 144x85x46mm |
Net Weight (not including batteries) | 252g | |
Package | Package | giftbox, instruction manual, EVA case or softbag, strap, cleaning cloth, USB cable, AV cable, Micro SD card (optional) |
Box Dimension | 122x197x65mm | |
Net Weight / Box | 423g | |
Quantity / Master Carton | 10pcs | |
Net Weight / Master Carton | 4.23kgs | |
Gross Weight / Master Carton | 4.83kgs | |
Dimension / Master Carton | 335x245x225mm | |
