* Straight Eyepiece: Straight eyepiece can quickly find and track moving targets.
* Zoom Magnification: Poweful continuous zoom magnification of 20X to 60X makes it easy to zoom in on target for a closer and detailed look.
* Wild Field of View: Large field of view is good for fast moving subject and shorten distance between users and target.
* FMC Lenses and Coated Prism: Fully multi and ultra wide band coated lenses and quality roof prism improve the color and contrast of images and maximize brightness.
* Dual Focus Wheel System: Dual speed focusing system for smooth and accurate focusing sees the details of a target easily even if the target is far away.
* Angle Adjusting Knob: To rotate angle adjusting knob for comfortable viewing at any angle.
* Adjustable Twist-up Eyecup: Whether you wear glasses or not, adjustable eyecups allow you to comfortably enjoy the viewing.
* Built-in Sunshade: Extendable sunshade on objective lens barrel reduces stray light interference when watching.
* Fully Waterproof and Fogproof: The nitrogen-filled tube ensures fully waterproof and fogproof performance.
* Non-slip and Shock-proof: Durable framework with high-quality rubber armor and rubber painting structure provides effective non-slip grip, just need one hand to hold it, as well as shock-proof.
* Tripod: All-metal tripod hole can match any tripod, and ensures steady viewing in any situation.
* Phone Adpater: A professional phone adpater ensures stable views and easy photography and recording.
Basic Functions | Coarse and Fine Focusing Adjustments | Optional Functions | Smart Phone Adapter |
Fine Left-right Tube Adjustment | |||
Kill Flash on Objective Part | |||
Fast Connection to A Tripod | |||
Fast Connection to A Smart Phone | Bluetooth Remote | ||
Waterproof-IPX7 (Nitrogen Filled) | |||
Fogproof | |||
Dustproof | |||
Shockproof |
Item No. | LR-NSP01SW 80 | Field Of Angel | 1.9~0.9° |
Model | 20-60x80 | Apparent Field of Angle | 38~54° |
Magnification | 20-60X | Field of View | 33~16m/1000m |
Clear Aperture | 80mm | Exit Pupil | 4~1.33mm |
Ocular Lens Coating | FMC | Eye Relief | 14~12mm |
Objective Lens Coating | FMC | Brightness | 16~1.8 |
Prism / Prism Coating | BAK4 / Yes | Near Focus | 8m |
Focus | Prism | Waterproof Grade | IPX7 |
Eyepiece Cup | Twist-up | Nitrogen Filled | Yes |
1 | 2 | 3 | 4 | 5 | 6 | 7 |
Premium FMC Ocular Lens | Twist-up Eyepiece | Large FMC Objective Lens | Coarse and Fine Focus Rings | Kill Flash | Tube Left-right Adjustment | Tripod Mount |
LR-NSP01SW 80 | ||
Product | Dimension (WxHxD) | 425x93x97mm |
Net Weight | 965g | |
Package | Package | giftbox, blister shell, regular case, instruction manual, cleaning cloth |
Box Dimension | 514x116x217mm | |
Quantity / Inner Carton | -- | |
Quantity / Master Carton | 6pcs | |
Net Weight / Master Carton | 9.10kgs | |
Gross Weight / Master Carton | 10.56kgs | |
Dimension / Master Carton | 525x375x465mm | |
